hunter pro c controller manual

Components and Accessories Included

The Hunter Pro-C Controller includes a base module for up to 4 stations, station modules for expansion, and necessary wiring components. Accessories like the Solar Sync sensor, remote control, and EZ Decoder Module enhance functionality. The system supports compatibility with EZ-1 decoders and various sensors, ensuring comprehensive control and customization for efficient irrigation management.

Installation Instructions

Mount the controller indoors or outdoors, connect wiring to station modules, and install solenoids. Follow manual guidelines for proper setup and system testing to ensure functionality.

Connecting the Controller to the Water Supply

Connect the Hunter Pro-C controller to the water supply by ensuring the solenoid wires are properly attached to the zone valves. Use a 13 mm UL-listed conduit for AC wiring and install a 15A rated overcurrent device. Always check that the water supply is turned on and verify connections to avoid leaks or water flow issues during operation.

• Ensure the water supply is turned on before testing.
• Inspect solenoid connections for tightness.
• Use appropriate adapters for secure wiring.

Installing Station Modules and Wiring

The Hunter Pro-C controller comes with a factory-installed base module for up to 4 stations. To add more stations, install PCM modules as needed. Connect station modules securely to the controller, ensuring proper alignment and tightening. Wire the solenoid connections to the zone valves, using the correct polarity. Always use UL-listed conduit for AC wiring and follow safety guidelines to prevent electrical issues.

• Use a screwdriver to secure module connections.
• Ensure proper polarity for solenoid wiring.
• Test all connections before powering on.

Mounting the Controller Indoors or Outdoors

The Hunter Pro-C controller can be mounted indoors or outdoors. For outdoor installations, use the weather-resistant enclosure to protect against elements. Ensure the controller is securely fastened to a wall or post. Keep it away from direct sunlight and moisture. Indoors, mount near a water supply and power source. Follow all safety guidelines and ensure proper ventilation for optimal performance.

• Use screws to secure the controller firmly.
• Protect outdoor units from harsh weather conditions.
• Avoid exposing the controller to extreme temperatures.

Basic Programming and Setup

The Hunter Pro-C controller offers straightforward programming. Start by setting the current time and date. Then, create a watering schedule based on your lawn’s needs. You can choose between manual and automatic modes for flexibility. The interface is user-friendly, making it easy to adjust settings as necessary.

Setting the Clock and Date

Setting the clock and date on your Hunter Pro-C controller is essential for proper scheduling. Turn the dial to access the menu, then use the arrow buttons to adjust the time and date. Press the dial to save your settings. Ensure the time and date are accurate, as this affects programmed watering schedules. Incorrect settings may lead to improper irrigation timing, so double-check for accuracy.

Creating Watering Programs and Schedules

Creating watering programs on the Hunter Pro-C controller involves defining start times, duration, and frequency for each zone. Access the menu by turning the dial to “Programs,” then select the desired program to configure. Set the run times, watering days, and soil moisture levels to customize your irrigation schedule. Adjust settings based on plant type, soil, and slope for optimal efficiency. Save your configuration to ensure proper operation.

Understanding Manual and Automatic Modes

The Hunter Pro-C controller offers two primary modes: Manual and Automatic. In Manual mode, users can manually activate individual stations or a single zone for immediate watering. Automatic mode runs pre-programmed schedules, allowing the controller to manage watering cycles independently. Switching between modes is done via the dial, ensuring flexibility for different irrigation needs and preferences. This dual functionality enhances convenience and efficiency in lawn care management.

Advanced Features and Customization

The Hunter Pro-C controller offers advanced features like Cycle and Soak, Solar Sync Delay, and integration with sensors and remotes for tailored irrigation management and improved water efficiency.

Using the Cycle and Soak Feature

The Cycle and Soak feature on the Hunter Pro-C controller allows for efficient water distribution by breaking irrigation cycles into shorter periods with soaking intervals. This prevents runoff, especially on slopes or dense soils. Activate it via the controller settings to optimize water absorption and tailor irrigation to specific landscape needs, enhancing overall watering efficiency and conservation.

Connecting to Hunter Sensors and Remotes

Connecting Hunter sensors and remotes to the Pro-C controller enhances functionality and customization. The Solar Sync sensor adjusts watering based on weather conditions, while remotes enable manual operation from a distance. Installation involves wiring the sensor to the controller or pairing wireless devices, ensuring seamless communication. Refer to the manual for specific connection steps and compatibility details to optimize your irrigation system’s performance and convenience.

Setting Up Solar Sync Delay

Setting up Solar Sync delay on the Pro-C controller allows you to adjust the sensor’s weather-based adjustments. This feature delays irrigation cycles based on weather conditions, optimizing water usage. To set up, navigate to the Solar Sync menu, adjust the delay duration (1-7 days), and enable the feature. This ensures watering occurs only when necessary, promoting water conservation and system efficiency while adhering to local regulations.

Troubleshooting Common Issues

Troubleshooting common issues ensures optimal performance. Check connections, verify settings, and consult the manual for guidance on resolving issues like no water flow or display malfunctions.

Diagnosing No Water Flow Problems

If no water flows, check if the water supply is shut off at the zone valves. Turn the solenoid counterclockwise to ensure it’s open. Verify the controller is in RUN mode and schedules are active. Inspect wires for damage and ensure all connections are secure. Check for valve issues or blockages in pipes. Refer to the manual for detailed troubleshooting steps.

Resolving Controller Display Issues

If the display is blank or unresponsive, restart the controller by turning it off and on. Check for loose wiring connections and ensure the power supply is stable. Clean the screen gently with a soft cloth to remove dirt or debris. If issues persist, refer to the manual or contact Hunter Pro-C support for further assistance or potential firmware updates.
